Product Description:
Dante Audio Controller: The Ultimate Audio Control Device for Your
Audio Needs
Dante Audio Controller is a sophisticated tool used to manage and
route audio signals over a Dante network, which is a widely used
audio-over-IP protocol. It allows users to control audio flows,
configure channels, and monitor the status of audio devices on the
network.
Key Specifications
Network Protocol Support:
Fully supports Dante audio networking protocol.
Compatibility with AES67 and SMPTE 2110 standards for broader
interoperability.
Channel Capacity:
Capable of managing hundreds of audio channels simultaneously.
Allows for both unicast and multicast audio routing.
Latency and Synchronization:
Ultra-low latency performance, typically below 1ms.
Automatic sample rate conversion and precise clock synchronization.
Control Interface:
User-friendly software interface for easy setup and configuration.
Available for both Windows and macOS platforms.
Supports drag-and-drop routing of audio channels and real-time
adjustments.
Scalability:
Scalable architecture to accommodate both small-scale installations
and large-scale audio networks.
Allows for easy addition of Dante-enabled devices to expand the
system.
Monitoring and Diagnostics:
Provides real-time status monitoring of all Dante devices on the
network.
Built-in diagnostic tools for troubleshooting connectivity and
performance issues.
Redundancy and Reliability:
Supports redundant networking with primary and secondary
connections for maximum reliability.
Ensures uninterrupted audio transmission in case of network
failure.
Technical Parameters:
| Product Name | Dante Audio Controller |
|---|
| Type | Audio Controller |
|---|
| Dimensions | 7.9 X 5.9 X 2.2 In |
|---|
| Connection | Ethernet |
|---|
| Outputs | 8 X XLR/TRS Combo Jacks |
|---|
| Inputs | 8 X XLR/TRS Combo Jacks |
|---|
| Sampling Rate | 44.1/48/88.2/96 KHz |
|---|
| Bit Depth | 24-bit |
|---|
| Signal-to-Noise Ratio | >100dB |
|---|
| Compatibility | Windows/Mac |
|---|
| Processor | ADI SHARC 21489 |
|---|
Applications:
The Vincan NLP44 Dante Audio Controller is perfect for a wide range
of audio applications, including:
- Live Performances: With its real-time control and easy operation,
the NLP44 Dante Audio Controller is ideal for enhancing live
performances.
- Studio Recording: The high sampling rate and bit depth of the NLP44
Dante Audio Controller make it perfect for studio recording,
ensuring high-quality sound.
- Sound Reinforcement: The NLP44 Dante Audio Controller sound
optimization and dynamic range make it perfect for sound
reinforcement in any environment.
Here are some possible scenarios where the NLP44 Dante Audio
Controller can be used:
- A live band using the NLP44 Dante Audio Controller to mix and
enhance their audio during a concert.
- A recording studio using the NLP44 to capture high-quality audio
during a recording session.
| Brand Name | Vincan |
|---|
| Model Number | NLP44 |
|---|
| Place of Origin | China Mainland |
|---|
| Certification | CE, FCC, Rohs |
|---|
| Minimum Order Quantity | 1 unit |
|---|
| Price | 100-1000 USD/set |
|---|
| Packaging Details | Standard export package |
|---|
| Delivery Time | 2-3 days |
|---|
| Payment Terms | T/T, Western Union/PayPal |
|---|
| Supply Ability | 1000 sets per week |
|---|
| Sampling Rate | 44.1/48/88.2/96 KHz |
|---|
| Bit Depth | 24-bit |
|---|
| Dimensions | 7.9 X 5.9 X 2.2 In |
|---|
| Dynamic Range | >100dB |
|---|
| Type | Audio Controller |
|---|
