Product Description:
The LCD Video Wall Controller is a core device designed to manage multiple LCD screens,
transforming them into a large, seamless video wall. It is widely
used in surveillance centers, command rooms, corporate meeting
spaces, and advertising displays. The LCD Video Wall controller can
distribute input video signals to multiple LCD displays, supporting
various display modes such as full screen, split screen, zoom, and
overlay. With its high-performance image processing capabilities,
it ensures crisp and smooth visuals even at high resolutions.
This LCD Video Wall controller enables users to control and manage
multiple signal sources via intuitive software, allowing for
real-time switching and flexible video wall configuration. It meets
the demands of various applications requiring large-scale screen
displays.
Technical Parameters:
| Input signal | |
| VGA | HD15 interface and link with 1 audio interface of 3.5 Support 640*480/85HZ to 1920*1200/60HZ |
| HDMI | HDMI 1.4(HDCP 1.3) DVI 1.0 ,HDMI embed audio |
| Video | Automatic identification the syetem of NTSC,PAL and SECAM,link with
1 audio interface of 3.5 |
| USB | Standard interface of 2.0,can insert U disk,embed audio; Support video,image,MP3,TXT |
| Output signal | |
| HDMI interface | 4 HDMI output,support joint pattern of 2*2,1*4,4*1; Support customizing output signal of 2 to 25; 1920*1080P/60HZ,1280*720,60HZ; |
| Audio | 3.5 Audio interface,support left and right channels and stereo,AV
signal switch synchronously |
| others | |
| Control mode | RS232,Remote ,case key |
| Power supply | AC: 100 to 240 V |
| Joint pattern | Quad standard joint,single machine customize joint of 2 to 25 |
| Power | 20W |
| Case size | |
| Dimensions(1U) | 1U 19 inch standard crate,442mm(L)*45mm(H)*242mm(W) |
| Weight(1U) | 2.5KG |
Applications:
.
The LCD Video Wall Controller is suitable for a variety of
applications and scenarios, such as:
- Trade Shows and Exhibitions: The LCD Video Wall controller can be
used to create eye-catching and interactive displays at trade shows
and exhibitions, helping to attract and engage potential customers.
- Control Rooms and Command Centers: TheLCD Video Wall controller is
ideal for control rooms and command centers, where real-time
control and monitoring of multiple screens is required.
- Conference Rooms: With the LCD Video Wall controller, conference
rooms can have a professional and high-definition display, making
presentations, meetings, and video conferencing more effective and
engaging.
- Entertainment Venues: The LCD Video Wall controllercan be used in
entertainment venues like cinemas, theaters, and sports arenas, to
create a stunning and immersive visual experience for the audience.
- Retail Stores: Retail stores can use the VWP to showcase their
products and promotions on multiple screens, creating an attractive
and dynamic display.
- Public Transport: The LCD Video Wall controller can be used in
public transport systems, such as airports and train stations, to
provide real-time information and updates to passengers on multiple
screens.
