7U 4K HDMI Video Wall Controller 4 Ch Input 16 Ch 1080P HDMI Output

Ask Lasest Price
Brand Name :	VINCAN
Model Number :	WL-HDVP
Certification :	CE,FCC and RoHs
Price :	Negotiable
Payment Terms :	T/T, Western Union, MoneyGram
Supply Ability :	1000 pcs per week
Delivery Time :	2-3 days

Add to Cart

Product Details
Company Profile

7U 4K HDMI Video Wall Controller 4 Ch Input 16 Ch 1080P HDMI Output

7U 4K Video Wall Controller 4 Ch Input 16 Ch 1080P HDMI Output

Product Introduction:

All video wall controller adopted Integrated control function which Offers integrated control serial ports,

supporting RS232, RS485, DMX512 protocols, in order to control the projector on/off, video wall screen on/off,

projection curtain up/down.

Technical Parameters

WL-HDVP series HD video wall processor
Description	Up to sixteen video windows per display channel
Inputs (optional)	DVI/HDMI/VGA/YpbPr/VIDEO/SDI/S-Video
Input resolution	XGA/SXGA/SXGA+/UVGA/WUXGA/1080p,etc, compatible with custom ultra-high resolution
Output signal	DVI/VGA output
Output resolution	1920*1200/60HZ (compatible with standard resolution )
System control software	CCS Client end,ApplicationPro dedicated control software
Power	Dual power supplies 100AC~240VAC,50/60Hz, more trustable hot-swappable power supply working mode, internationally self-adaptive power
Consumption	12w per channel
Working temperature	"-20℃--60℃
Working humidity	5-95%
Serial port	RS-232, 9 pin, D-type connector
Chassis size	1U/2U/3.5U/7U/12.5U standard rackmount chassis
Baud rate	115200
Serial port architecture	2=TX,3=RX,5=GND
Ethernet control port	RJ-45 female ports, TCP/IP protocol
Ethernet control speed	Self-adaptive 10M or 100M,Full duplex or half duplex
Working hours	7 days x 24 hours

7U 4K HDMI Video Wall Controller 4 Ch Input 16 Ch 1080P HDMI Output using application fields:

7U 4K HDMI Video Wall Controller 4 Ch Input 16 Ch 1080P HDMI Output

One processor controls several video walls
It can control a video wall plus auxiliary monitors or even multiple video walls which share the input sources.

The outputs are separate and adjustable in teams of resolutions, colors and other parameters.

Real-time sync of the video wall pictures on PC or iPad/Android Pad
Users can preview all the pictures of input signal through control software before switching and

can see the whole video wall pictures using the same UI control software.

Integrated control function
Offers integrated control serial ports, supporting RS232, RS485, DMX512 protocols, in order to control the projector on/off,

videowall screen on/off, projection curtain up/down.
