4k 1080P 4x4 HDMI Video Wall Controller Self Adaptive Power

Product Categories
Shenzhen Winlink Technology Co., Limited
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 4k 1080P 4x4 HDMI Video Wall Controller Self Adaptive Power from wholesalers

    Buy cheap 4k 1080P 4x4 HDMI Video Wall Controller Self Adaptive Power from wholesalers
    • Buy cheap 4k 1080P 4x4 HDMI Video Wall Controller Self Adaptive Power from wholesalers

    4k 1080P 4x4 HDMI Video Wall Controller Self Adaptive Power

    Ask Lasest Price
    Brand Name : VINCAN
    Model Number : WL-HDVP
    Certification : CE,FCC and RoHs
    Price : Negotiable
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1000 pcs per week
    Delivery Time : 2-3 days
    • Product Details
    • Company Profile

    4k 1080P 4x4 HDMI Video Wall Controller Self Adaptive Power

    4k 1080P 4x4 HDMI Video Wall Controller Self Adaptive Power​

    Introduction:
    4k 1080P 4x4 HDMI Video Wall Controller Self Adaptive Power processes a full range of I/O resolutions
    including 3840 x 2160, 2048 x 1152 and 1920 x 1080 via Dual-link DVI, HDMI1.4 or DP.

    Technical Parameters

    Description4k 1080P 4x4 HDMI Video Wall Controller Self Adaptive Power
    Inputs (optional)DVI/HDMI/VGA/YpbPr/VIDEO/SDI/S-Video
    Input resolutionXGA/SXGA/SXGA+/UVGA/WUXGA/1080p,etc, compatible with custom ultra-high resolution
    Output signalDVI/VGA output
    Output resolution1920*1200/60HZ (compatible with standard resolution )
    System control softwareCCS Client end,ApplicationPro dedicated control software
    PowerDual power supplies 100AC~240VAC,50/60Hz, more trustable hot-swappable power supply working mode, internationally self-adaptive power
    Consumption12w per channel
    Working temperature"-20℃--60℃
    Working humidity5-95%
    Serial portRS232, 9 pin, D-type connector
    Chassis size4U/6U/10U/15U standard rackmount chassis
    Baud rate115200
    Serial port architecture2=TX,3=RX,5=GND
    Ethernet control portRJ-45 female ports, TCP/IP protocol
    Ethernet control speedSelf-adaptive 10M or 100M,Full duplex or half duplex
    Working hours7 days x 24 hours



    One processor controls several video walls
    It can control a video wall plus auxiliary monitors or even multiple video walls which share the input sources. The outputs are separate and adjustable in teams of resolutions, colors and other parameters.

    Application fields for 4k 1080P 4x4 HDMI Video Wall Controller Self Adaptive Power:
