Product Description:
The MINI DVI Optical Fiber Transmitter is designed to provide
high-performance, long-distance transmission of uncompressed DVI
video signals over fiber optics. It supports resolutions up to
1080p for clear, high-quality video and ensures zero-latency
transmission, making it suitable for live broadcasting, video
conferencing, and security applications. This compact transmitter
offers a simple plug-and-play solution for easy integration into
any AV setup or broadcast environment, supporting both real-time
video and HD video transport over fiber.
Features:
- Uncompressed Video: Supports uncompressed DVI video for superior HD
video quality.
- Compact and Portable: Small, easy-to-integrate design for versatile
use in broadcast and AV setups.
- Resolution Support: 1080p HD video transmission ensures excellent
clarity and resolution.
- Zero-Latency: Ideal for real-time video transmission with no
delays, perfect for live streaming and video communication.
- Long-Distance Fiber Optic Transmission: Fiber optics allow for
long-distance video transport, reducing the need for bulky cables.
- Easy Integration: Plug-and-play design for seamless setup with DVI
devices and AV equipment.
- Low Power Consumption: Energy-efficient for continuous operation in
various environments.
- Durable Design: Built for reliability in professional environments.
Technical Parameters:
| Video | HDMI compatible | HDMI 1.3 |
| DVI compatible | DVI 1.0 |
| Video bandwidth | 10.2Gbps |
| Video resolution | 480i ~1080p50/60Hz, 1920x1200@60Hz; HDMI resolution up to 4K30HZ
backward compatible |
| Color space | RGB, YCbCr 4:4:4 / 4:2:2, YUV 4:2:0 |
| Color depth | 8/10/12-bit (1080P60Hz) |
| HDMI audio format | LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD |
| Transmission distance | 2KM (single-mode optical fiber), does not support multi-mode
optical fiber transmission |
| Electrostatic protection | Human body model: ±8kV (air discharge), ±4kV (contact discharge) |
| Port | transmitter | Input port: 1 x DVI-D [19-pin female] 1 x Micro USB Output port: 1 x FIBER |
| receiver | Input port: 1 x FIBER1 x Micro USB Output port: 1×DVI-D [19-pin female] |
| Fuselage | shell | Zinc alloy shell |
| colour | Black |
| dimension | Transmitter/receiver: 75.5mm(L)× 41mm(W)×16.5mm(H) |
| weight | Transmitter: 113g, receiver: 111g |
| Power source | DC 5V/1A |
| Maximum power consumption | Transmitter: 2.74W (Max), receiver: 3.03W (Max) |
| Operating temperature | 0-40℃ |
| Relative humidity | -20-90%RH (non-condensing) |
| Storage temperature | - 20-60℃ |
Applications:
Broadcasting: Reliable high-definition video transmission for live
events and media production.
AV Systems: Ideal for AV integration, conference rooms, and control
centers.
Video Conferencing: Supports real-time video communication with
high-quality video transport.
Security Monitoring: Transmits video signals over long distances
for surveillance systems.
Educational Systems: Used for distance learning and training
applications requiring high-quality video.
